These boards are not recommended for new designs
We can build batches for existing customers.
System
- 60 MHz ARM7 CPU (LPC2103)
- IEEE 754 floating-point support
Size
- 50 x 80 mm
- Compatible with Hammond 1455C801 enclosure
Storage
- 32k Flash code space
- 8k RAM
Power
- 350 mW
- 7-12V DC input
- Provides 500 mA +5V
Connectors
- USB-B type
- Connections for 24 digital I/O
- 8 x 10 bit analog A/Ds
- Accepts 0.1” components, DB Style and 3.5mm terminal strips
Prototyping Area
- 2 square inches
